輪式多功能液壓攪拌機產品廣泛適用于建筑工程、市政工程、公立、橋梁、城鄉道路、預制廠、小型預制構件廠等工業及民用建筑工程施工部門攪拌干性混凝土、塑性混凝土、流動性混凝土



施工場所，特別適用于在狹窄的艙底建筑修建、維修，能大大提高工作效率。包裝

屬性Specifications 單位Unit 參數Parameter

實際攪拌量Actual stirring capacity m3 1.2

攪拌筒容量Rotary drum capacity m3 1.4

傾斜角Degree of bias ° 16

轉動速度Rotational speed r/min 0-14

轉動方向Direction of rotation 進料：順時針出料：逆時針

Feed:clockwise output:counter clockwise

攪拌筒葉片Mixing drum blade 兩組螺旋葉片及四組輔助葉片Two sets of spiral blades and four sets of auxiliary blades

混凝土坍落度Slump of concrete mm 70-260

液壓傳動系統Hydraulic Power Transmission System

油泵型號Pump model CBGV-4025

馬達型號Hydraulic motor model BMSS-250

減速機速比Reducer ratio 01：10

供水系統Water Supply

水箱容量/供水形式Tank capacity/ water supply form L 540/自帶式自動訂時自動常通供水機構

540/ automatic timing water supply mechanism with automatic timing

底盤主要性能參數發動機主要性能參數The main performance parameters of the chassis and the main performance parameters of the engine

發動機型號/排量Engine type / displacement L CF4B68G-Z-13B2/CF4C100T-Z-13B2

形式model 直噴式四沖程水冷增壓柴油機

Straight injection type four stroke water cooled supercharged diesel engine

額定功率Rated power kw/r/min 55KW/2400 78KW/2400

樶大扭矩Max torque N.m/r/min 255/1500-1800 380/1500-1800

樶大行駛速度Max running speed km/h 24

樶小轉彎半徑Min steering radius mm 5000

爬坡能力Climbing capacity % 26

輪胎Tire 23.5/70-16

驅動形式Driving way 4×4

整車裝備質量Weight kg 4580

樶大裝載質量Maximum load capacity kg 2800

樶大車輛總質量Whole machinery weight kg 7380

整車外形尺寸（長*寬*高）Overall size(L*W*H) mm 6100*1850*3000
