ezSTM 原子力顯微鏡技術規格 • 1pA-10nA or 100pA-100 nA current range
• 0.1 pA current step size
• 0.5x0.5x0.2 μm or 1x1x0.5 μm (XYZ) Scanner
• Z resolution 0.5 pm
• X Y resolution 1 pm
• Constant current, constant height imaging modes
• Current-Voltage, Current-Distance spectroscopy
• Tip voltage ± 15 V in 300 μV steps
• Ultrasonic motors for fastest sample approach & X Y
coarse sample positioning up to 5mm
• Sample reception up to 15 mm
• 2MP CMOS, LED illuminated side view video camera
• with manual focusing and 5X digital zooming.
電子控制器 • Digital feedback with FPGA/DSP
• 24bit ADCs/DACs
• Simultaneous scan of 6 channels @ 4,096x4,096 pixels
• USB interface
• 100-240 VAC, 50/60 Hz, 50 W
軟件 • Control Software and Image Analyzer
• Free software upgrades for lifetime
• Unlimited user licens
?
